Solar power is the most environmentally friendly, safe, and clean renewable energy source available for your home. Getting your electricity from the sun saves you money and shows that you care about the environment.

You’ll need a variety of specialized electronic tools and parts to get solar energy. Solar panels are the most significant of them all; they capture photons from the sun and transform them into AC.

You’ll need many solar panels if you want to utilize them to power your entire home. When buying a new panel or dealing with a problem after a storm, you may need to examine if the panel is functional.

There are a few things you can do to make sure your solar panels are up to the task. In this article, I’ll show you how to inspect a solar panel so you don’t have to rely on a malfunctioning panel.

Benefits of testing solar panels

A solar panel’s power rating is determined by the manufacturer, and the number simply signifies the amount of power that solar panels can generate under perfect conditions.

Solar panels, on the other hand, are rarely exposed to perfect circumstances for more than a few hours per day in reality.

The number of peak sun hours in a day, shading concerns, the outside temperature, the direction the solar panels are facing, the geographic location of the solar panels, and the particular season when the solar panels are being utilized can all affect solar panel efficiency and power generation.

You can get an accurate assessment of how much solar power your solar panels generate by testing them. Not only will this allow you to alter your expectations to reflect the genuine potential of your solar panels, but it will also tell you whether you need to buy more solar panels or simply reposition the ones you have.

In essence, testing your solar panels will allow you to ensure that they are producing enough power to satisfy your demands and will inform you if they need to be reinstalled to optimize their performance and obtain the most solar electricity out of your system.

Signs of a working solar panel

To do what it does, the solar panel you attach to the roof has a sophisticated mechanism. It captures photons from the sun, converts them to DC, and transfers it to an inverter for conversion to AC.

To run the home appliances, you need air conditioning, and the entire system works together to provide that.

When the inverter produces a faulty output, you know something is wrong with the process. If the inverter appears to be in good working order, most inspections begin with the solar panels.

There could be a problem with the panels if you’re getting less current, getting an unexpected energy bill, or obtaining anomalous solar meter readings.

Best means to test solar panels

If you’re having trouble with your home’s solar power system, testing a solar panel is a must-do chore. If you’re buying a single panel for an RV or a boat, testing is also required.

Because you are not going to pay an expert for that minor job, you should test it before using it.

There are several simple ways to test your solar panel, particularly if it is a single panel that is not permanently mounted to the roof.

You may need to disconnect the panels from the roof and test them individually if it’s mounted to your roof. In the majority of circumstances, a multimeter will suffice.

Things to know about solar panels

If you want to use solar energy effectively in your home, you must understand solar panel systems. Here are some of the most crucial aspects of solar panels to be aware of:

  • Solar panels are intended to help you save money by lowering your reliance on the grid for energy. Even the grid energy company will compensate you if you give the excess energy produced to the grid.
  • Solar panels typically last 25 years or more, making them excellent investments. They will, however, come at a hefty one-time expense, most of which will be spent on solar panels.
  • You can install a solar energy system in your home as a backup system to power all of your current electric gadgets. During the day, though, you will need to use an inverter and a battery pack to store electricity.
  • Solar panels can only power tiny gadgets like DC lamps and fans. If you’re going camping and won’t be able to bring a generator, the solar panels will come in handy.
  • Solar panels require almost no maintenance because they are robust and rigid enough to last for years. You would, however, need to clean up after yourself regularly and perform routine maintenance checks.

A guide: testing the solar panel

If you want to see if your solar panel is working properly, you must test it, and there are several ways to do so. Here’s how to test a solar panel in the most efficient method possible, which everyone can do:

Comprehend the procedure and procure tools

The Voltage Open Circuit, or VOC, is the first item you should check on your solar panel. The short circuit current, or ISC, is the second thing to check on the panel.

A conventional multimeter may be used to test both of them; you can find one in any electronics store. Choose mid-afternoon to test the panel because it will receive the most sunshine.

Examine the VOC

In the rear of the solar panel, there is a printed specification list and a terminal box. Check the panel’s specification list to see how much VOC it is rated for. Take, for example, a panel with a VDC rating of 21.7.

Set the multimeter to a higher reading than the VDC reading; for 21.7, this will be 200. Connect the negative and positive leads to the terminal according to the imprinted instructions.

Now, place the panel in direct sunshine and see how much light it reflects on the meter. If you take the panel away from the sun, you’ll receive a reading that’s pretty close, if not accurate, and it’ll go down.

Examine the ISC

Check the manufacturer’s specifications to see how much current the ISC can handle; at 21.7 V, that’s 2.65 Amps. Switch the positive lead connector on the multimeter to the empty one on the left.

Set the voltmeter to the figure that is more than the ISC rating; in this case, 10 amps. Connect the positive and negative leads to the panel terminal, which should be towards the sun. The panel is functioning properly if you obtain 2.65 or close to it.

Examining solar charge controller

A solar charge controller is a regulator that controls the voltage or current from solar panels to prevent overcharging of the batteries. Although a charge controller is appropriate, it is not always necessary, especially when dealing with small panels of less than 5 watts.

However, 12v panels with a high output require a charge controller to prevent battery overload.

There are two types of charge controllers. You can acquire maximum power point tracking (MPPT) or buy a pulse-width modulation (PWM). PWMs are straightforward devices that employ a switch that opens and shuts quickly enough to manage the electricity generated by a solar panel.

MPPTs, on the other hand, are more sophisticated. They figure out what the ideal operating voltage is for generating the greatest electricity. Although MPPTs are more expensive, they are not always superior to PWMs in terms of technology.

What is the best way to test the charge controller?

  • To measure DC amps, place the leads in the appropriate positive-positive and negative-negative slots.
  • Connect everything as follows with the meter set to -10A: The solar panel is connected to a controller, which is connected to a battery.
  • Remove the positive cable from the controller’s battery connection. After that, connect the meter’s positive to the positive cord.
  • Finally, connect the meter’s negative lead to the positive terminal of the battery.
  • The current flowing to the battery from the solar panel and the controller will be seen through this connection.

Possible solar panel issues

You must take good care of your solar panels once they have passed the test. If you run into any issues, get them rectified as quickly as possible to guarantee optimal performance.

Wiring issues

These electrical faults may impair the performance of your panels. You might consult an electrician if you have any loose connections or rusted cables. Solar panels should not be tampered with unless you are a certified technician.


measure solar panel output

Solar panel cracks can be so small that they go unnoticed. However, weather-related damages may exacerbate the problem.

Small cracks are common during transportation as a result of mishandling. You should hire an expert to move the panels from the start.

Hot spots

Hot spots on your solar panel are so harmful that they can completely damage your system. Hot spots might occur if your panels are overloaded or overheated.

Hot spots are usually caused by a buildup of debris on the panels and improperly soldered joints. The performance of your panels may suffer if they have hot spots.

Birds living beneath the panels

Birds can scratch your panels and damage the cables if they build a nest under them. Plastic strips can be fastened to the panels to remedy this problem.

Alternatively, roof-integrated panels can be installed, leaving no openings for birds to nest.

Inverter problems

Inverters have a far shorter lifespan than solar panels, which can last up to 20 years. There’s no need to be concerned if your solar inverter needs to be replaced every 10 to 15 years.

However, if inverter difficulties arise too soon, you should consult the manufacturer’s terms. Check the warranty to discover whether you’re eligible for a replacement.

Roof defects

Solar panels, when installed correctly, can offer adequate roof coverage. Roof rots and other noticeable deterioration can be covered. They can also help to extend the life of your roof by preventing it from being damaged by the elements.

A poorly built system, on the other hand, can cause damage to your roof. As a result, consider hiring a professional to install the panels for you.


Here are some of the most frequently asked questions regarding solar panels and how they function in a home. If you have solar power or plan to get it for your home, you’ll find them useful:

What is the capacity of a solar panel?

A solar panel that is one square foot in size produces 1.5 watts, which equates to around 250 watts when exposed to full sunshine for four hours.

To generate 1 kWh of electricity, you’ll need four identical panels in your configuration.

Is it possible to use solar panels without an inverter?

You don’t need an inverter if you don’t plan to use your usual, full-sized electric items in your home. When traveling, direct current from the panel can be used to power small appliances.

Is it possible to use solar panels at night?

Because there is no sunshine to absorb, solar panels will not work at night. However, you can use an inverter and a battery in conjunction with the panels to store energy for later use.

Last Thoughts

Solar panels are the energy sources in any solar energy system, and they contain a variety of mechanisms. It absorbs sunlight, collects photons, and converts them into Direct Current electricity to power a gadget.

You’ll need a larger panel and inverters if you wish to power all of your home appliances.

A larger panel setup will require a large budget, which is a concern for the wallet! You must keep them in good working condition by testing them regularly, and I attempted to explain how to test a solar panel to you.

You may now test your solar panels without hiring an expert and make an informed decision. Good luck!
